Design and function
Verti-Mix SF / Verti-Mix Double SF Version 06.12
55
5.2.3 Open door window
WARNING
Risk of injuries to people / animals due to careless opening and
closing of door window!
Ensure that there are no people / animals within the swivelling range
of the door window before opening and closing the window.
WARNING
Risk of injuries and accident to people / animals due to
accidental opening or closing of the door window during travel!
 Never open or close the door window in a careless or
uncontrolled way.
 Ensure that the door window is safely locked in open position.
1. Turn the locking lever (2) and open the door
window (1).
2. Swivel the door window until the open door
window engages in the locking mechanism
thus being secured against accidental
slamming.
Fig. 18
5.2.4 Close door window
1. Unlock the open door window.
2. Close the door window.
3. Turn the locking lever (2) to lock the closed
door window.
