Strautmann Verti-Mix SF - Pick-Up Milling Cutter; Protective Device of Pick-Up Milling Cutter; Hydraulic Counter-Cutters (Optional Extra)

Design and function
Verti-Mix SF / Verti-Mix Double SF Version 06.12
77
5.7.6.5 Pick-up milling cutter
901
Pick-up milling cutter forward
Indicates whether the switching input is active.
902
Pick-up milling cutter backwards
Indicates whether the switching input is active.
921
Milling pressure
Indicates the milling pressure.
931
Pick-up milling cutter in driving direction "Filling".
Indicates the electric current.
932
Pick-up milling cutter in driving direction "Reversing".
Indicates the electric current.
903
Safety button of pick-up milling cutter
Indicates whether the switching input is active.
5.7.6.6 Protective device of pick-up milling cutter
a01
Open protective device of pick-up milling cutter
Indicates whether the switching input is active.
a02
Close protective device of pick-up milling cutter.
Indicates whether the switching input is active.
a03
Protective device of pick-up milling cutter open
No function.
a41
Protective device of pick-up milling cutter opens
Indicates whether the switching output is active.
a42
Protective device of pick-up milling cutter closes
Indicates whether the switching output is active.
5.7.6.7 Hydraulic counter-cutters (optional extra)
641
Hydraulic counter-cutters extend
Indicates whether the switching input is active.
642
Hydraulic counter-cutters retract
Indicates whether the switching input is active.
