Strautmann Verti-Mix SF - Video Surveillance; Weighing Device

Design and function
64
Verti-Mix SF / Verti-Mix Double SF Version 06.12
5.7.2 Video surveillance
Irrespective of the operating mode, the rear-view camera picture is
displayed during reverse travel.
The displaying camera may be manually switched at any time by
touching the camera picture as often as is necessary to select the
desired camera.
The displaying camera can be switched in the "Parameter" menu. For
details refer to page 81.
Your machine is equipped with a maximum of 3 video surveillance
cameras:
 rear-view camera,
 video surveillance camera in the mixing container
 video surveillance camera according to customer request
(optional extra).
Depending on the current operating mode, the following angles of
view are preset for the camera:
Operating mode Camera
"Charging" Video surveillance camera in the
mixing container
"Discharging" Video surveillance camera in the
mixing container
"Transport" Surveillance via rear-view camera
5.7.3 Weighing device
Depending on the machine’s equipment, it is fitted with:
 a programmable weighing device offering the possibility to save
several recipes,
 a programmable weighing device offering the possibility to save
several recipes and to transfer data to the PC (optional extra).
For programming the weighing device, observe the information in the
chapter ""Weighing device" menu", page 90.
A
ll weighing procedures are automatically saved and can be analysed
on the PC if necessary and if the appropriate software is available.
