Design and function
Verti-Mix SF / Verti-Mix Double SF Version 06.12
67
Direction of motion Backwards
Direction of motion Backwards selected.
Page 136
"Charging" mode
"Charging" mode selected
Page 111
"Discharging" mode
"Discharging" mode selected
Page 112
"Transport" mode
"Transport" mode selected
Page 110
Front axle steering
Lights up green with the front axle steering properly working.
Lights up yellow with a slightly defective front axle steering.
Lights up red with a seriously defective front axle steering.
Page 142
Four-wheel steering
Lights up green with the four-wheel steering properly working.
Lights up yellow with a slightly defective four-wheel steering.
Lights up red with a seriously defective four-wheel steering.
Page 142
Parking brake
Grey with the parking brake deactivated.
Lights up red with the parking brake activated.
Page 139
Fuel quantity
Lights up green at large fuel quantity.
Lights up red at small fuel quantity.
Press the key for analog display of the fuel quantity.
Page 124
"Parameter / Diagnosis / Weighing device" menu
Opens a submenu. Enables the assignment of functions to display keys /
keys of the multi-function joystick, the modification of machine parameters,
the modification of scales settings and the performance of error diagnosis.
Page 70
