The S3™ MedSurg Bed, Model 3002 Patriot™ Series is suited for use in the electromagnetic environment specified
below. The customer or the user of the S3™ MedSurg Bed, Model 3002 Patriot™ Series should assure that it is used
in such an environment.
Immunity Test IEC 60601 Test Level
Compliance
Level
Electromagnetic Environment - Guidance
Conducted
RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
3 Vrms
150 kHz to 80 MHz
3 V/m
80 MHz to 2.5 GHz
3 Vrms
3 V/m
Portable and mobile RF communications
equipment should be used no closer to any
part of the S3™ MedSurg Bed, Model 3002
Patriot™ Series, including cables, than the
recommended separation distance calculated
from the equation appropriate for the
frequency of the transmitter.
Recommended Separation Distance
d=1,2
d=1,2
d=2,3
80 MHz to 800 MHz
where P is the maximum output power rating
of the transmitter in watts (W) according to
the transmitter manufacturer and d is the
recommended separation distance in meters
(m).
Field strengths from fixed RF transmitters,
as determined by an electromagnetic site
survey
a
should be less than the compliance
level in each frequency range.
b
Interference may occur in the vicinity of
equipment marked with the following symbol:
Note 1
At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2
These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection
from structures, objects and people.
a
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land
mobile radios, amateur radio, AM and FM radio broadcast, and TV broadcast cannot be predicted theoretically with
accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey
should be considered. If the measured field strength in the location in which the S3™ MedSurg Bed, Model 3002
Patriot™ Series is used exceeds the applicable RF compliance level above, the S3™ MedSurg Bed, Model 3002
Patriot™ Series should be observed to verify normal operation. If abnormal performance is observed, additional
measures may be necessary, such as reorienting or relocating the S3™ MedSurg Bed, Model 3002 Patriot™ Series.
b
Over the frequency range 150 kHz to 80 MHz, field strengths are less than 3 V/m.
