FFiigguurree 3311 –– TTPPSS aasssseemmbbllyy
7. Using a 1/4" ratchet and a T25 Torx driver, remove the two button head cap screws (G) that secure the TPS assembly
(H) (Figure 32).
NNoottee
• Slightly lift up on the trolley mechanism arm to pull the cable through to remove the TPS. Discard the TPS.
• Do not dispose of as unsorted municipal waste. Refer to your local distributor for return and/or collection systems
available in your country.
G
H
FFiigguurree 3322 –– TTPPSS aasssseemmbbllyy bboottttoomm vviieeww
8. Reverse steps to reinstall.
9. Verify proper operation before you return the product to service.
6390-309-002 Rev AB.0 49 EN
