FU(H4SO)-10
FUEL INJECTION (FUEL SYSTEMS)
General Description
(1) Heat shield cover (11) Clip (21) Fuel pipe ASSY
(2) Fuel tank band (12) Evaporation hose B (22) Fuel return hose B
(3) Protector RH (13) Joint pipe (23) Evaporation hose E
(4) Fuel tank (14) Evaporation hose C (24) Evaporation hose F
(5) Fuel pump gasket (15) Evaporation pipe ASSY (25) Evaporation hose G
(6) Fuel pump ASSY (16) Evaporation pipe
(7) Fuel level sensor (17) Fuel return hose A Tightening torque: N·m (kgf-m, ft-lb)
(8) Fuel cut valve gasket (18) Retainer T1: 4.4 (0.45, 3.3)
(9) Fuel cut valve (19) Quick connector T2: 7.4 (0.75, 5.4)
(10) Evaporation hose A (20) Evaporation hose D T3: 33 (3.4, 24.3)
