FU(H4SO)-12
FUEL INJECTION (FUEL SYSTEMS)
General Description
(1) Clip (11) Fuel pipe ASSY (21) Two-way valve drain hose A
(2) Fuel delivery hose A (12) Grommet (22) Connector
(3) Fuel filter bracket (13) Canister hose A (23) Two-way valve drain hose B
(4) Fuel filter holder (14) Canister (24) Clamp
(5) Fuel filter cup (15) Canister bracket plate (25) Front canister bracket
(6) Fuel filter (16) Cushion
(7) Evaporation hose (17) Canister bracket spacer Tightening torque: N·m (kgf-m, ft-lb)
(8) Fuel damper (18) Rear canister bracket T: 23 (2.3, 17.0)
(9) Fuel delivery hose B (19) Two-way valve return hose
(10) Fuel return hose (20) Two-way valve
