FU(H4SO)-13
FUEL INJECTION (FUEL SYSTEMS)
General Description
6. FUEL FILLER PIPE
(1) Fuel filler pipe ASSY (6) Air vent pipe (11) Filler cap tether
(2) Evaporation hose holder (7) Air vent pipe holder (12) Filler pipe protector
(3) Clip (8) Filler pipe packing
(4) Clamp (9) Filler ring Tightening torque: N·m (kgf-m, ft-lb)
(5) Air vent hose (10) Filler cap T: 7.4 (0.75, 5.4)
FU-00956
(4)
(2)
(8)
(1)
(12)
(11)
(6)
(7)
(9)
(10)
(5)
(3)
(3)
T
T
T
T
T
