EX(H4SO)-5
EXHAUST
General Description
B: CAUTION
• Wear working clothing, including a cap, protec-
tive goggles and protective shoes during operation.
• Remove contamination including dirt and corro-
sion before removal, installation or disassembly.
• Keep the disassembled parts in order and pro-
tect them from dust or dirt.
• Before removal, installation or disassembly, be
sure to clarify the failure. Avoid unnecessary re-
moval, installation, disassembly, and replacement.
• Be careful not to burn your hands, because each
part on the vehicle is hot after running.
• Be sure to tighten fasteners including bolts and
nuts to the specified torque.
• Place shop jacks or rigid racks at the specified
points.
• Before disconnecting electrical connectors of
sensors or units, be sure to disconnect the ground
cable from battery.
(1) Front exhaust pipe upper cover (16) Cushion rubber (29)
Rear catalytic converter upper
cover(2) Front exhaust pipe lower cover (17) Rear exhaust pipe
(3) Clamp (18) Clamp (30) Rear catalytic converter lower
cover
(4) Front exhaust pipe upper cover LH (19) Center exhaust pipe upper cover
(5) Front exhaust pipe lower cover LH (20) Center exhaust pipe lower cover (31) Rear catalytic converter
(6) Front exhaust pipe (21) Protector
(7) Front exhaust pipe lower cover RH (22) Gasket Tightening torque: N·m (kgf-m, ft-lb)
(8) Front exhaust pipe upper cover RH (23) Front oxygen (A/F) sensor T1: 8 (0.8, 5.8)
(9) Gasket (24) Front catalytic converter T2: 13 (1.3, 9.4)
(10) Spring (25) Center exhaust pipe T3: 18 (1.8, 13.0)
(11) Chamber (26) Front catalytic converter lower
cover
T4: 21 (2.1, 15.2)
(12) Gasket T5: 30 (3.1, 22.4)
(13) Gasket (27) Front catalytic converter upper
cover
T6: 35 (3.6, 26.0)
(14) Self-locking nut T7: 48 (4.9, 35.4)
(15) Muffler (28) Rear oxygen sensor
To Next Page
