LU(H4SO)-17
LUBRICATION
Oil Pan and Strainer
Tightening torque:
5 N·m (0.5 kgf-m, 3.6 ft-lb)
5) Lower the engine onto front crossmember.
6) Tighten the nuts which install the front cushion
rubber onto front crossmember.
Tightening torque:
69 N·m (7.0 kgf-m, 50.9 ft-lb)
7) Install the front and center exhaust pipes. <Ref.
to EX(H4SO)-7, INSTALLATION, Front Exhaust
Pipe.> and <Ref. to EX(H4SOw/oOBD)-7, INSTAL-
LATION, Front Exhaust Pipe.>
NOTE:
Always use new gaskets.
8) Install the under cover.
9) Lower the vehicle.
CAUTION:
When lowering the vehicle, lower the lifting de-
vice and wire rope together.
10) Remove the lifting device and steel cables.
11) Install the pitching stopper.
Tightening torque:
T1: 50 N·m (5.1 kgf-m, 36.9 ft-lb)
T2: 58 N·m (5.9 kgf-m, 42.8 ft-lb)
12) Install the radiator upper brackets.
13) Install the resonator chamber. <Ref. to
IN(H4SO)-7, INSTALLATION, Resonator Cham-
ber.>
14) Install the air intake duct and air cleaner case.
<Ref. to IN(H4SO)-6, INSTALLATION, Air Intake
Duct.> and <Ref. to IN(H4SO)-5, INSTALLATION,
Air Cleaner Case.>
15) Install the front wheels.
LU-00031
LU-00030
LU-00035
LU-00028
ME-00218
T2
T1
LU-00027
