EN(H4SO)(diag)-22
ENGINE (DIAGNOSTICS)
Electrical Components Location
• SOLENOID VALVE AND SWITCH (AT MODELS)
• SOLENOID VALVE AND SWITCH (MT MODELS)
(1) Shift solenoid valve 1 (4) Low clutch timing solenoid (7) 2-4 brake timing solenoid
(2) Shift solenoid valve 2 (5) Lock up duty solenoid (8) Transfer duty solenoid
(3) Line pressure duty solenoid (6) 2-4 brake duty solenoid (9) Inhibitor switch
(1) Neutral position switch
AT-00334
(1)
(6)
(7)
(2)
(3)
(4)
(5)
AT-00335
(8)
EN-01415
(9)
EN-00192
