FU(H4SOw/oOBD)-10
FUEL INJECTION (FUEL SYSTEMS)
General Description
(1) Heat shield cover (13) Evaporation hose B (25) Evaporation hose E
(2) Fuel tank band (14) Joint pipe (26) Fuel sub level sensor gasket
(3) Protector LH (15) Evaporation hose C (27) Jet pump filter
(4) Protector RH (16) Evaporation pipe ASSY (28) Fuel sub level sensor
(5) Fuel tank (17) Evaporation pipe (29) Evaporation hose F
(6) Fuel pump gasket (18) Fuel return hose A (30) Evaporation hose G
(7) Fuel pump ASSY (19) Jet pump hose
(8) Fuel level sensor (20) Retainer Tightening torque: N·m (kgf-m, ft-lb)
(9) Fuel cut valve gasket (21) Quick connector T1: 4.4 (0.45, 3.3)
(10) Fuel cut valve (22) Evaporation hose E T2: 7.4 (0.75, 5.4)
(11) Evaporation hose A (23) Fuel pipe ASSY T3: 33 (3.4, 24.3)
(12) Clip (24) Fuel return hose B
To Next Page
