FU(H4SOw/oOBD)-34
FUEL INJECTION (FUEL SYSTEMS)
Intake Air Temperature and Manifold Absolute Pressure Sensor
9. Intake Air Temperature and
Manifold Absolute Pressure
Sensor
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Disconnect the spark plug cord from ignition coil
and ignitor ASSY.
3) Disconnect the connector from intake air tem-
perature and manifold absolute pressure sensor.
4) Remove the intake air temperature and manifold
absolute pressure sensor.
B: INSTALLATION
Install in the reverse order of removal.
NOTE:
• For tightening torque, refer to “COMPONENT”.
<Ref. to FU(H4SOw/oOBD)-3, COMPONENT,
General Description.>
• Replace the O-ring with a new one.
FU-00009
FU-00934
FU-00935
FU-00936
FU-00296
To Next Page
