EX(H4SOw/oOBD)-5
EXHAUST
General Description
B: CAUTION
• Wear working clothing, including a cap, protec-
tive goggles, and protective shoes during opera-
tion.
• Remove contamination including dirt and corro-
sion before removal, installation or disassembly.
• Keep the disassembled parts in order and pro-
tect them from dust or dirt.
• Before removal, installation or disassembly, be
sure to clarify the failure. Avoid unnecessary re-
moval, installation, disassembly, and replacement.
• Be careful not to burn your hands, because each
part on the vehicle is hot after running.
• Be sure to tighten fasteners including bolts and
nuts to the specified torque.
• Place shop jacks or safety stands at the specified
points.
• Before disconnecting electrical connectors of
sensors or units, be sure to disconnect the ground
cable from battery.
(1) Front exhaust pipe upper cover (12) Rear exhaust pipe cover (23) Center exhaust pipe upper cover
(2) Front exhaust pipe lower cover (13) Gasket (24) Rear exhaust pipe
(3) Clamp (14) Self-locking nut (25) Gasket
(4) Front exhaust pipe upper cover LH (15) Muffler
(5) Front exhaust pipe lower cover LH (16) Cushion rubber Tightening torque: N·m (kgf-m, ft-lb)
(6) Front exhaust pipe (17) Upper clamp T1: 8 (0.8, 5.9)
(7) Front exhaust pipe lower cover RH (18) Lower clamp T2: 13 (1.3, 9.6)
(8) Front exhaust pipe upper cover RH (19) Protector T3: 18 (1.8, 13.3)
(9) Gasket (20) Gasket T4: 30 (3.1, 22.1)
(10) Spring (21) Center exhaust pipe T5: 35 (3.6, 25.8)
(11) Chamber (22) Center exhaust pipe lower cover T6: 48 (4.9, 35.4)
To Next Page
