FU(H4SO)-6
FUEL INJECTION (FUEL SYSTEMS)
General Description
(1) Intake manifold gasket RH (11) Intake manifold (21) Plug cord holder RH
(2) Fuel injector pipe (12) Intake manifold gasket LH (22) Accelerator cable bracket
(3) Fuel injector (13) Fuel pipe protector LH (23) EGR valve
(4) O-ring (14) Plug cord holder LH
(5) O-ring (15) Fuel pipe protector RH Tightening torque: N·m (kgf-m, ft-lb)
(6) O-ring (16) Fuel pipe ASSY T1: 1.5 (0.15, 1.1)
(7) Plug (17) Fuel hose T2: 6.4 (0.65, 4.7)
(8) PCV valve (18) Clip T3: 17 (1.7, 12.5)
(9) Purge control solenoid valve (19) Clip T4: 19 (1.9, 13.7)
(10) Nipple (20) Guide pin T5: 25 (2.5, 18.1)
