81307063I
EN
19
2.6 Common P1 – P4
Inthisoptionaremanyusefulfunctionstoavoidfutureproblems,likeMotor protector auto reset,Pump exercis-
ing,Pump reversing,anddi󰀨erentscenariosforblockingwhenusingPower monitor.
Motor protector auto reset
Canbedone“Conventional”orbyCA622“Motor drive.
Conventional needs a digital output which controls an
externalsolenoidtoresetthemotorprotector.
Motor drive requires CA 622 and the reset is sent to the
VFDviasoftware
Pump exercising
Itispossibletoexercisesomepumpsifrequired.
Amaximumpumpo󰀨timecanbesetandexercising
time. The level must be within the parameters.
Pump reversing
Several parameters can trigger reversing.
See also chapter 5
2.7 Set log settings and events
There are 16 analog log channels which can be allocated to 26 log functions. Recommended to use the log
channels in order from channel 1 and upwards. To have one or more log channels disabled between active
channelswillcostdatatra󰀩ctothesurveillancesystem.
Thelogsarekeptinthecontrollerfor15daysandtheoldestwillbedeletedwhenthememoryisfull.
Thesettingsare:
Log signal
Log function
Log interval
There are 34 Log signals which can be logged.
The Log functionscanbesetasfollows:
Closed
Actual value
Average value
Min value
Maxvalue
Closed: Nologging
Actualvalue: Amomentarilyvaluewillbestoredatthelogsequence.
Averagevalue: Anaveragevalueduringthelogintervalwillbestored.
Minandmaxvalue: Theminorthemaxvalueintheintervalwillbestored.
The log interval can be set from 1 minute to 1440 minutes.
Table 2-7:
Log functions
Level in pump pit
Inow
Outow
Overow level
Overow ow
Back-pressure
Motor currents P1-P4
Pump capacity P1-P4
Power factor (Cos)
Temperature stator wiring
Temperature upper bearing
Temperature lower bearing
Vibration
Main voltage
Main frequency
AI free choice
Supply voltage
Pulse channel
Temperature stator wiring L2
Temperature stator wiring L3
PID controller output
Data register
Data register (2-compl)
Actual VFD frequency
Measured pump head
Actual pump head
