2.2 Congurethedigitalinputs,digitaloutputs,analoginputsandanalog
outputs
SetdesignatedIO-functionsaccordingtotheelectricalwiringdrawing.Seeyourdrawingsofthestation.
Under Settings, Digital inputs; choose for each input according to table 2-1 and Digital outputs to table 2-2.
Digital outputs
OFF
Pump control
Reset motor protector
Pump fail
Too many pumps blocked
One pump fail
Master reset motor protector
Mixer control
Reset motor protector Mixer
Drain pump control
Reset motor protector Drain
Cleaner control
Modem control
Remote control
Personnel alarm
High level
Alarm alert
Not ackn. A-alarm
Not ackn. A/B-alarm
Active A-alarm
Active A/B-alarm
Pump reversing
Active B-alarm
Logic IO
Data register set point
Extern reset alert
Under Settings, Analog inputs,chooseforeachinputaccordingtotable2-3.Analoginput1isxedtoleveland
cannot be changed.
Table 2-3: Table 2-4:
Analog input 2-5
OFF
Motor current P1-P4
Back-pressure
Vibrations
Free choice
Vibrations P1-P4
Xylem MiniCas Sim P1-P4
Outow meter
Note
 Analog1ispredenedtolevelsensor
and cannot be changed.
Analog outputs
OFF
Pit level
Pit inow
Pit outow
Pit overow
Pulse channel 1
Pulse channel 2
Pulse channel 3
Pulse channel 4
PID controller
Data register
Table 2-1: Table 2-2:
Digital inputs
OFF
Pump run indication
Manual pump start
Pump not in auto
Start oat
Pump failure
Motor protector
High temperature
Leakage
Stop oat P1-P4
Low level oat
Overow sensor
High level oat
Drain pump oat
Run indicator Drain pump
Motor protector Drain pump
Run indicator Mixer
Motor protector Mixer
Staff in station
Alarm reset
Power fail
DI pulse channel 1-4
Block PID controller
Alarm input
Mixer block + Alarm input
Drain pump block + Alarm input
Block remote data
