3.2.1 Pit shape
ThecontinuousowmeasurementisbasedonthefactthatthePC441cancalculatethevolumebymeasuring
theleveldi󰀨erenceduringasetcalculationtime.Forthiscalculationistoexactitisnecessarythatthearea/
levelshouldbealwaysknown.Thiscanbeachievedbysettingthelevelandareaforalllevelwherethepit
changesshape,upto9breakpoints+theareaatzeropointcanbeset.
Rectangular Cone Cone
Figure 3-4 Exampleofpitshapes.
Togetacorrectcalculationatalllevelseventhepitshapehastobesetasthecalculationisdi󰀨erentfordi󰀨er-
entgeometricalshapes.Ashapethatendsinapointissetasconical,ifitendsasawedge(2parallelsides)it
issetasrectangularshape,seegureabove.
Example for area calculation:
Rectangle Circle
A = L * W Ex. A = pi * r
2
Ex.
A =Area A =? A =Area A =?
L =Length L =2.20Meter pi =3.14... D =2.50meter
W =Width W =1.75meter R =Radius=D/2 R =2.5/2=
1.25 meter
A =2.2*1.75 A =3.14*(1.25)
2
A=3.85m
2
A=4.91m
2
