2 CONFIGURETHEPC441
Overview of settings
Eachstationhasanuniquecongurationsetup,buttheprocedureissimilartosetupthese.Thischapterwill
guideyouthroughthebasicsettingsinPC441.Note:Thisdoesnotcoverallcongurations,youmustconsider
yourprerequisites.
The menu item Settingshas21submenuswithmanysettingsthatneedtobeenteredbythesystemadmin-
istrator(althoughtheyallhavesensibledefaultvalues).Thefollowing9notesbelowarearecommended
procedure to setup PC 441.
2.1. Setgeneralconguration,system-andcommunicationsettings
2.2. ConguredesignatedIOfunctionsatDI,DO,AIandAOaccordingtotheelectricalwiringdrawing
2.3. CongureI/Omodules,CA441,CA442,CA443,CA622,CA511andCA781
2.4. Pump pit parameters and alarms
2.5. Set pump 1 - 4 settings and their alarms
2.6. Common P1-P4
2.7. Set log settings and events
2.8. Setupcommunicationstosurroundingunits(VFD,softstartersand/orenergymeters(ifused)
2.9. Setupcleaner,mixerordrain(ifused)
Each of the 21 submenus under settings are described in separate tables in section 5.
To enter the settings area:
Press down arrowonceandyouareinthemenus,continuetopressdownarrowtoSettings,pressEnter.
ThemajorityofsettingsrequireapasscodeforSystemexceptsomesettingsunderthesub-menuSystem and
the start/stop levels under submenus Pump 1-4whichonlyrequireapasscodeforOperator.
AllthesettingscanbedonelocallyformthemenusorbyAquaProg.TheadvantageofAquaProgisyoucan
savethecongurationatyourPCandeasilyrestorethecontrollerifneeded.
2.1 Setgeneralconguration,system,IDandcommunicationsettings
SetupthebasicsystemparametersandcommunicationparametersbyusingthemenusinCA511:
Basic system parameters
• Fromthebasescreen,pressthekeyforSettingunderthedisplay,pressEntertwiceandgivethe
password (default 2).Scrollontheleftpartofthescreentoyourlanguagebyusingtheup/down
arrowkeys,pressEnteratyourchoice.
• UsethedownarrowkeytoStation application and press Enter. Select Pump controller or Pump
monitor byusingtheup/down arrow in the left part of the screen, pressEnteratyourchoice.Use
thedownarrowkeytoMain graphics and choose the base screen (Pump pit statusoranypump)
• UsethedownarrowkeytoSelect units,metricorUSunits,pressEnteratyourchoice.
• UsethedownarrowkeytoDate format,pressEnter.Chooseyourdateformat.
• UsethedownarrowkeytoSet date,Set time,andallothersettingsunderthisparameter.
• Set System alarmsaccordingtoyourpreferences.
