1 OVERVIEWOFFUNCTIONSANDUSAGE
PC 441 is designed to control 1-4 pumps. It can operate a pump station stand alone and/ or as a pump monitor.
ForcongurationandoperatorinteractionthegraphicoperatorpanelCA511maybeused.WiththeAquaProg
software(evaluationversionavailable)aPCcanbeusedforcongurationandbackupofsettings.Byadding
amodem,afullremotealarmandmonitoringsolutioncanbeachievedwithjustanAquaWebrentalcontract
orbymostSCADAsystems.Optionalmonitoringmodulesforleakage,temperatureandelectricalparameters
givesahighlyscalablesolutionforoptimalcostandperformance.
ThePC441canworkstandaloneortogetherwithextensionmodules,buttheextensionmodulescannotwork
without the PC 441.
.
As a pump monitoring devicethePC441o󰀨ersthemarketacombinedstandardsolutionforsubmersible
pump and pump station surveillance. Can be set up for full-scale monitoring of one or up to four submersible
pumps plus ancillaries.
As a pump controllerthePC441controlsthestart/stopofthepumps,o󰀨eringastandardizedsolutionfor
sewagepumpstationswithuptofourpumps.Avarietyofsolutionsfromstandardon/o󰀨controluptoad-
vancedVFDsupportincludingpumpcapacitycalculation.
As a combined control and monitoring devicethePC441canbeo󰀨eredasasolutionsupportingboththe
areas above in a single unit.
Modules:
1. CA 511 - Graphical operator interface
Max 1 of this unit per system
2. CA 622 - RS 485 Communication interface module
Max 1 of this unit per system
3. PC 441 - Pump monitoring and/or controller
4.CA781-Analoganddigitaloutexpansionmodule
Max 1 of this unit per system
5. CA 441 - Moisture monitoring module
Max 4 of this unit per system
6. CA 442 - Temperature monitoring module
Max 6 of this unit per system
7.CA443-Motorandsupplypowermonitoringmodule
Max 5 of this unit per system
PC 441 is the heart
ofthesystem!Other
modules are optional.
1.
2. 3. 4.
5. 6. 7.
