Sulzer ABS PC 441 - Page 60

81307063I
EN
56
Submenu Submenu Submenu Setting Value Pass code Comment
Calc.Overow
OverowDetect
(OFF,Overow
Sensor; Level Limit)
System
Todetectoverow,anoverow
sensor is much more accurate
than a threshold from the level
sensor.Bysettingparameters
(exponentsandconstants)the
overowcanalsobeaccurately
measuredbyacalculation.‘Lock
oninow’simplyusesthehis-
toricalvalueofinow.
Level Limit is the level at which
overowisexpected.Note:not
asaccurateasusinganoverow
switch.
See Section 3.2
Level if Limit Used m,ft
OverowCalculation
(Exp+const,
LockonInow)
Calc.Overow
Exponent1 Number
System
Overow=h
e
¹c
1
+ h
e
2
c
2
(m
3
/s or
ft
3
/s)
h=heightofwater(morft)
See Section 3. 2 .1
Constant 1 Number
Exponent2 Number
Constant 2 Number
BackupRun
Pump 1
BackupStart
(OFF,ON)
System
If the normal control via start
andstoplevelsfails,thismay
actasanemergencybackup:
Ifthehigh-leveloattriggers,
pumps1,2,3and/or4maybe
set to start running for a period
of Running Time.
...
...
...
...
Pump 4
BackupStart
(OFF,ON)
Backup
Running Time
Seconds
Pit Alarms
High Level
AlarmType
(Inactive,
B-Alarm,A-Alarm)
System
AlarmDelay Seconds
Limit m,ft
Hysteresis m,ft
Low Level
AlarmType
(Inactive,
B-Alarm,A-Alarm)
AlarmDelay Seconds
Limit m. ft
Hysteresis m,ft
High Level Float
AlarmType
(Inactive,
B-Alarm,A-Alarm)
Blockal.ifpumpruns
(No,Min1pump,
Min2pumps,...
Min 4 pumps)
Ifpump(s)runningnormally
when the High Level Float will
generate a B-alarm.
AlarmDelay Seconds
Low Level Float
AlarmType
(Inactive,
B-Alarm,A-Alarm)
AlarmDelay Seconds
HighInow
AlarmType
(Inactive,
B-Alarm,A-Alarm)
AlarmDelay Seconds
Limit Liters/second,GPM
Hysteresis Liters/second,GPM
LowInow
AlarmType
(Inactive,
B-Alarm,A-Alarm)
AlarmDelay Seconds
Limit Liters/second,GPM
Hysteresis Liters/second,GPM
