Submenu Submenu Submenu
Setting
Value Passcode Comment
Pump Parameters
NominalCurrent Amperes
System
NominalPowerFactor Number
Pump Run Indication
Pump Run Indication
(OFF,DigitalInput,
Motor Current)
System
Themeans/sensorbywhicha
pump is regarded as running.
Current Threshold Amperes
Pump is regarded as running
above threshold.
Time Settings
ThresholdOnDelay
Seconds
System
Delaybeforechangeofsetpoint
status.
ThresholdO󰀨Delay
Seconds
MaxRuntime
Stop Pump
(OFF,ON)
MaxContinu-
ous Runtime
Minutes
Pumps are stopped when Max
Continuous Runtime is reached.
The timer is reset each time a
start level is reached.
PumpCurve(QH)
Point1Hmax
Tot. Head
m,ft
System
Lowest level (pump outlet)
Highest head
See Section 3.2.2
Point 1 Flow
Liters/second,GPM
Point 2 Hmid
Tot. Head
m,ft
Mid level
See Section 3.2.2
Point 2 Flow Liters/second,GPM
Point 3 Hmin
Tot. Head
m,ft
Highest level in the pit.
Lowest head
See Section 3.2.2
Point 3 Flow Liters/second,GPM
Total Head Sen-
sor Zero
m,ft
Often the sensor 0-point is lower
then the outlet of the pump. In
thiscasethedi󰀨erencemustbe
added to the head.
See Section 3.2.2
Pump
Alarms
Phase Missing
AlarmType
(Inactive,
B-Alarm,A-Alarm)
System
AlarmDelay Seconds
DryRun
AlarmType
(Inactive,
B-Alarm,A-Alarm)
AlarmDelay Seconds
NoRunConrm
AlarmType
(Inactive,
B-Alarm,A-Alarm)
AlarmDelay Seconds
Fallen Motor Protector
AlarmType
(Inactive,
B-Alarm,A-Alarm)
AlarmDelay Seconds
M. Prot. Reset Error
AlarmType
(Inactive,
B-Alarm,A-Alarm)
AlarmDelay
Seconds
High Motor Current
AlarmType
(Inactive,
B-Alarm,A-Alarm)
AlarmDelay Seconds
Limit Amperes
Hysteresis Amperes
Low Motor Current
AlarmType
(Inactive,
B-Alarm,A-Alarm)
AlarmDelay Seconds
Limit Amperes
Hysteresis Amperes
