Sulzer ABS PC 441 - Page 65

81307063I
EN
61
Submenu Submenu Submenu
Setting
Value Passcode Comment
Pump
Alarms
High Tem -
peratur
Temp.
Stator L2
AlarmType
(Inactive,
B-Alarm,A-Alarm)
System
FromadditionalCA442:
Same set point are used for
AlarmLimitandHysteresisas
T1/T4 (Pt100)
AlarmDelay Seconds
Temp.
Stator L3
AlarmType
(Inactive,
B-Alarm,A-Alarm)
AlarmDelay Seconds
PumpBlock
Auto Reset
Stop On High Temp.
T1/T4 Stator or
DigitalInputor
MiniCas
[1]
simulation
on Analog Input
(NO,YES)
System
If activated the pump will be
blockedaslongthealarmlimitis
exceeded.
Use alarm limits from the pump
alarms menu.
Independentonalarmtype.
T2 Upper Bearing (NO,YES)
T3 Lower Bearing (NO,YES)
Manual Reset
Required
(NO,
YES for T1/T4
DigitalIn,
YES for all Temp.)
IfsettingisYES,thepumpwill
beblockeduntiltheconditionis
backtonormalandthereafter
manuallyresetfromthemenu
Main Menu – Manual Control
– Pump x –
Reset Temp. Protection
BlockDelay Seconds
Stop On Vibrations
Stop On Vibrations (NO,YES)
If activated the pump will be
blockedaslongasthealarm
limitisexceeded.Usealarmlim-
its from the pump alarms menu.
Independentonalarmtype
BlockDelay Seconds
StoponLeakage
DI1OilChamb.
(CA 441) or
MiniCas
[1]
simulation
on Analog In or
DigitalInput
(NO,YES)
DI2(CA441)
Electric Area
(NO,YES)
DI3(CA441)
Motor Housing
(NO,YES)
BlockDelay Seconds
BlockdelayworksonON/OFF
conditions.
PumpBlock
On Alarm
-
High Motor Current (NO,YES)
System
If setting is YES,thepumpwill
beblockeduntilthealarmis
acknowledged.
Low Motor Current (NO,YES)
Fallen Motor Protector (NO,YES)
LowPumpCapacity (NO,YES)
DryRun (NO,YES)
NoRunConrm (NO,YES)
Pump Error (NO,YES)
High Vibrations (NO,YES)
Blockon
High Temperature
DigitalInputor
MiniCas
[1]
simulation
on Analog Input
(NO,YES)
T1/T4 (CA 442) Stator
(NO,YES)
T2 (CA 442)
Upper Bearing
(NO,YES)
T3 (CA 442)
Lower Bearing
(NO,YES)
BlockonLeakage
DigitalInputor
MiniCas
[1]
simulation
on Analog Input
(NO,YES) System
If setting is YES,thepumpwill
beblockeduntilthealarmis
acknowledged.
DI1(CA441)
Oil Chamber
(NO,YES)
DI2(CA441)
Electric Area
(NO,YES)
DI3(CA441)
Motor Housing
(NO,YES)
(1)
Xylem;MiniCas=External monitoring relay
