Submenu Submenu Submenu Setting Value Passcode Comment
Power Moni-
tors CA 443
CA443-0
Main Power
-
Used and Con-
nected
(NO,YES)
System
OnlysetthistoYES if the units
are connected to Canbus and
used as power monitor.
Current
Measuring
Transf. Con-
nected to
(None,
L1,
L1andL2,
L1,L2andL3)
All current measuring is done
through current transformers.
TR.Nominal
Current
Amperes
TR. Second-
aryCurrent
Amperes
CurrentO󰀨set Amperes
CurrentDeadband Amperes
Filter Constant Seconds
Phase Com-
pensations
Value
Voltages
Measuring
Phases Connected
(None,
L1,
L1andL2,
L1,L2andL3,
NA,
Volt. from CA 443-1)
(NA=notavailable)
Ext.Transf.
Connected
(NO,YES)
O󰀨setVoltage Voltage
Filter Constant Seconds
Alarm Com.
Failure
AlarmType
(Inactive,B-
Alarm,A-Alarm)
AlarmDelay Seconds
High-leg
Delta
(NO,YES)
CA 443-1
Pump 1
to
CA 443-4
Pump 4
-
Used and Con-
nected
(NO,YES)
System
OnlysetthistoYES if the units
are connected to Canbus and
used as power monitor.
Current
Measuring
Trans. Connected to
(None,
L1,
L1andL2,
L1,L2andL3)
All current measuring is done
through current transformers.
TR.Nominal
Current
Amperes
TR. Second-
aryCurrent
Amperes
CurrentO󰀨set Amperes
CurrentDeadband Amperes
Filter Con stand Seconds
Phase Com-
pensations
Value
Voltages
Measuring
Phases Connected
(None,
L1,
L1andL2,
L1,L2andL3,
Volt. from CA443-0)
If voltage measuring
Ext.Transf.
Connected
(NO;
YES:PrimaryVoltage,
SecondaryVoltage)
O󰀨setVoltage Voltage
Filter Constant Seconds
