1-3
Optional accessories
Options
Description Part No. Remarks
Battery pack BU-11 Special Li-ion battery for TYPE-71C.
Car battery cable PCV-11 Plugged into a car’s cigarette lighter jack to supply
electric power to splicer
Battery charger BC-11 Use only for the battery pack BU-11.
Fiber holders FHD-1 For drop cable
Tools (Jacket remover, Fiber cleaver, and etc)
Consumables
Fiber protection sleeves
FPS-1
FPS-40*
FPS-S-40*
60mm (50 pcs per package) ••••• Cleave length 8-16mm
40mm (50 pcs per package) ••••• Cleave length 8-10mm
40mm (50 pcs per package) thin sleeve ••••• Cleave length
8-10mm
*The 40mm protection sleeves can be used only if the cleave
length is less than 10mm. Do not use the 40mm protection
sleeves for non-250μm coated fibers.
Description Part No. Remarks
Precision fiber cleaver FC-7R-S
FC-7S
FC-6S(-C)
FC-6S-5C
Applicable coating diameter: 250 - 900μm
Applicable fiber diameter: 125μm
Replacement blade for FC-7R: FCP-20BL(7R)
Replacement blade for FC-7 and FC-6: FCP-20BL
Jacket remover JR-M03 Applicable coating diameter: 250μm, 900μm
Applicable fiber diameter: 125μm
Dispenser HR-3 Dispenser for alcohol
The following optional accessories are provided for the TYPE-71C. For further details,
please contact our sales personnel.
[ JR-M03 ]
[ FC-6S-C ] [ FC-7R-S ]
