2-7
Operating procedures
If you press the power key right after connecting the power cord to the power supply
module, it may take a few seconds until the splicer is powered on.
Special note on monitors
Although bright spots or dark spots may appear on the screen, this is a unique characteristic of
liquid crystal displays, and such do not constitute or imply a machine defect.
1: Ensure that the electrodes are fully
inserted in the splicer.
2: Insert the output cord of the AC adapter
into the DC input terminal.
3: Adjust the monitor for optimum viewing
angles.
4: Press the power ( ) key for more
than 1 second to turn on the power.
The monitor viewing angle can be adjusted.
Turning on the TYPE-71C
Output cord of the AC adapter
To Next Page
