2-5
・ The battery pack can be charged while the splicer is operating.
However, it takes a long time compared with the time when the splicer is
stopping operating. (It takes about 14 hours.)
･Please charge the battery in the following temperature span. The battery
pack might be deteriorated (decrease in capacity) at the temperature
that exceeds this range.
*Temperature span for charging ： 0℃～+40℃
CAUTION
Insert the battery pack
LED (green)
Connect the
AC adaptor
Battery charging
1. Insert the battery pack into the TYPE-71C.
2. Connect the AC adapter with the TYPE-71C.
3. LED (green) on the side of the DC input terminal blinks, and the charge
begins.
4. It takes 2 - 3 hour to finish charging though it changes according to the
residual quantity of the battery. LED (green) lights when the charge
ends.
To Next Page
