6-4
Optical fiber
requirement
Material Silica glass
Profile type
SMF (ITU-T G.652), MMF (ITU-T G.651)
DSF (ITU-T G.653), CSF (ITU-T G.654),
NZDSF (ITU-T G.655, G.656), BIF (ITU-T G.657), EDF
Fiber diameter 80 – 150 μm
Fiber coating diameter 100 – 1,000 μm
Cleave length
*1
<up to φ1,000 μm>
5 – 16 mm
<Drop cable / Indoor cable>
10mm
Fiber count Single fiber
Size and
weight
Size (main body)
*2
120W × 154D × 130H (mm)
Weight Approx. 2.1 kg (with BU-11)
Monitor
4.1" touch screen color LCD display
Standard
performance
Typical splice loss
*3
SMF
MMF
: 0.02dB DSF : 0.04dB
: 0.01dB NZDSF : 0.04dB
Typical splice cycle time
*3
Approx. 7 seconds (Quick Mode)
Approx. 7.5 seconds (SMF Standard Mode)
Approx. 8 seconds (Automatic Mode)
Typical heating time
*1*4
Approx. 28 seconds
Splicing/heating operation per
fully charged battery
*5
Approx. 200
Functions Loss Estimation Provided
Splice data storage 10,000 splices
Splice image capture 64 splices
Proof test
*6
1.96N (200gf)
Heat shrink oven
Dual automatic independent heaters
(US patent 7,412,146)
Arc environment calibration
Automatically compensates for environmental
condition changes
Arc test Provided
V-groove white LED illumination Provided
Interface USB 2.0 mini-B type
Storage media SD / SDHC memory card
Universal clamps for tight & loose
buffer fiber
Provided
Reversible coating clamps Provided
User-selectable heater clamp operation
Provided
Software update Internet
Onboard user training video Provided
Remote interactive maintenance Provided
Programs Splice programs Max. 300
Heating programs Max. 100
Power supply AC operation
With ADC-1430
Input: AC 100-240V 50/60Hz 1.1A
DC operation Input: DC 10-15V, 4A
Battery operation (With BU-11) 11.1V (4600mAh)
DC output 12V For Sumitomo’s hot jacket remover
Environmental
conditions
Operation temperature
*7
-10 °C ~ +50 °C
Storage temperature
*7
*8
-40 °C ~ +80 °C
Altitude 0 to 6,000m
Windproof Max. 15m/s
Water & Dust resistance
Equivalent to IP52
*9
Shock resistance
Drop from 76cm on 5 faces
*10
Electrode life
3,000 arc discharges
*11
[TYPE-71C specifications]
