4-10
2/2
If “X or Y only” is selected, X or Y
screen is displayed on the screen.
If “X above Y” is selected, X and Y
screens are vertically displayed on
the screen.
If “X beside Y” is selected, X and Y
screens are horizontally displayed
on the screen.
Screen indication
In the function setting item of following sign, the displaying method of
the screen can be selected.
X or Y only
X above Y
X beside Y
Select Function
3/5
Light for v-groove
ON
Function
Date(dd/mm/yy hh:mm)
2011/01/01 00:00
Fiber Insert Screen
X above Y
Pre Fusion Screen
X or Y only
Select Function
4/5
Arc Screen
ON
Function
Post-Fusion Screen
Est. Loss Screen
Buzzer (Key)
X above Y
X or Y only
X beside Y
To Next Page
