Summa S ONE - Length Calibration

S One User’s Manual
Detailed operation 4-8
7. Use the arrows to set the sensitivity between 0 (most sensitive) and 4 (least sensitive).
The sensitivity is correctly set when if the sensor is covered, the indicator bar should be
(almost completely) black, and when it is not covered, (almost completely) white.
8. Ideally, the slider indicating the sensitivity trigger level should be halfway the indicator
bar, both when the sensor is covered and when it is not. If necessary, slide it to the left or
to the right.
9. Trigger level is set, tap
to confirm.
Length calibration is explained in section 2.5.
Back sensor
3
4.5.4 Length calibration
