Summa SummaSign D1010 - Screw; Flatwasher M2

Service Manual SummaSign
Figures 6-5
1 391-100
391-191
carriage plate 610/1010/1300
carriage plate 750
2 391-365 assy, excentric shaft
3 391-313 assy concentric shaft
4 391-314 assy flatcable holder
5 391-182 flatcable clamp
6 ND5000-9667
ND5000-9668
screw M2x4 (model 610/750)
screw M2x5 (model 1010/1300
7 ND5000-9267 flatwasher M2
8 ND5000-9540 hexnut M4
9 ND5000-9231 lockwasher M4
10 ND5000-9620 washer 8x4.1x.3
11 ND5000-9602 screw M2x6
12 see prev. page
13 ND5000-9587
ND5000-9604
lockwasher M3
screw M3
391-143 flatcable 610/750
390-643 flatcable 1010/1300
391-825 clear shield 915x25 (for 1010/1300)
