Summa SummaSign D1010 - Summasign; Summasign T1010 Plus Spare

Summasign Service Manual
SummaSign T1010 PLUS SPARE
End of Manufacture: Current
Part no Description
384-751 Assy LCD module
390-643 Flat cable head
391-254 Assy belt Y 1010 Plus
391-261 Drum
391-263 Assy sensor
391-311 Centron drag & tang.
board
391-312 Roller assy
391-318 Media sensor rear assy
391-319 Media sensor front assy
391-326 Assy pinch roller
391-342 Assy switch roller
391-344 Assy motor
391-346 Power entry module
391-367 Endcover left black
plastic
391-510 Set of core holders
391-600 Assy tangential head
391-655 Assy DC motor head
391-664 Assy nose piece long
391-666 Nose piece, sandblast
391-803 Fan assy
391-809 Motor without encoder
391-886 Cutting strip with tape
391-935 Final controller board
398-198 Pulley 24 tooth +
setscrew
423-155 Serial interface cable
MB0380 Belt 150T80
MB9121 Bearing
MB9129 Belt 140T80
MB9130 Belt 370T
MW9987 EPROM lo
MW9988 EPROM hi
ND5000-9702 Spring sprocket assy
Accessories and Consumables
390-549 Standard Tangential
Knife Blade (Single)
390-550 Tangential knife for
Masking stencil
(sandblast)
390-551 Double Tip Knife (single)
391-146 Manual Cut-Off razor
Blades (set of 10)
391-348 Razor Blade & Holder
391-360 Drag Knife Blade (set of
5)
391-500 Flange for Roll Media
(single)
391-510 Flanges for Roll Media
(pair)
391-596 Pouncing Tool
391-663 Tangential Knife Holder
391-664 Standard Nose Piece
391-666 Nose Piece for Masking
Stencil (sandblast)
391-667 Ballpoint Holder
391-668 Holder for Drag Knife
391-669 Ballpoint Pen
391-850 Cutter Stand (standard)
391-885 OPOS Field Upgrade Kit
423-155 Serial Interface Kit
MI9985 User’s Manual
7-14 Spare Parts List
