SummaSign T610 PRO SPARE PARTS
End of Manufacture: Current
Part no. Description
384-682 LCD cable
384-751 Assy LCD module
391-117 Spring
391-143 Flat cable
391-168 Display keyboard
391-282 Nameplate T610 Pro
391-312 Roller assy
391-315 Belt assy
391-317 Drive drum, Assy
391-318 Media sensor rear assy
391-319 Media sensor front assy
391-326 Assy, pinch roller
391-342 Assy, switch pinch roller
391-344 Assy, motor
391-346 Power entry module
391-366 Endcover right
391-367 Endcover left
391-386 Cutting strip with tape
391-510 Set of core holder
391-600 Assy, tangential head
391-601 Cover head
391-655 DC motor tang. head
391-935 Assy, final control board
421-198 Bearing block
MB0380 Belt 150T80
MB9124 Belt 110T80
MB9125 Belt 63T 2mm
ND5000-9622 Knob core holder
ND5000-9698 Brake O ring
ND5000-9769 Y belt spring
Accessories and Consumables
390-549 Standard Tangential Knife
Blade (Single)
390-550 Tangential knife for
Masking stencil (sandblast)
390-551 Double Tip Knife (single)
391-146 Manual Cut-Off razor
Blades (set of 10)
391-348 Razor Blade & Holder
391-360 Drag Knife Blade (set of 5)
391-400 Cutter Stand (optional)
391-500 Flange for Roll Media
(single)
391-510 Flanges for Roll Media
(pair)
391-596 Pouncing Tool
391-663 Tangential Knife Holder
391-664 Standard Nose Piece
391-666 Nose Piece for Masking
Stencil (sandblast)
391-667 Ballpoint Holder
391-668 Holder for Drag Knife
391-669 Ballpoint Pen
391-885 OPOS Field Upgrade Kit T-
series
423-155 Serial Interface Kit
MD9020 User’s Manual on CD
Spare Parts List 7-5
