Service Manual SummaSign series Cutters
Vertical misalignment. The knife tip deviates from its theoretical lateral centre.
This error can be corrected by means of the ADJUST LAT. test routine.
LONGITUDINAL deviation
LATERAL deviation
Theoretical centre
of the knife
Theoretical 0º
angle of the knife
ORIGIN deviation
POSSIBLE KNIFE CALIBRATION GROUNDS
The calibration settings entered during the knife calibration routine are automatically
stored in the cutter's memory and will be maintained after power down.
NOTE
Prior to knife calibration, load vinyl and install a knife to avoid damage to
the cutting strip.
ADJUST ORIGIN test routine
INTERNAL TESTS
CALIBRATE KNIFE
Keyboardcontrols 1-21
