SummaSign series Cutters Service Manual
Press to select the ORIGIN test.
ADJUST ORIGIN
0
Press
to execute the ORIGIN test.
This is the correctly cut test pattern.
Weed out the ring and compare the circle pattern cut in the vinyl with the circle pattern
illustrated above. If you obtained this kind of pattern, increase the value displayed on
the LCD by pressing the
jogging key to correct closing of the circles cut. To
repeat the test, press the
key.
Press the
key to go to the next step of the calibration procedure
However if you obtained the kind of pattern illustrated above, then, decrease the value
displayed on the LCD by pressing the
jogging key to correct closing of the circles
cut.
To repeat the test, press the
key.
Press the
key to go to the next step of the calibration procedure
1-22 Keyboardcontrols
