SummaSign T1300 PRO SPARE PARTS
End of Manufacture: Current
Part no. Description
384-682 LCD cable
384-751 Assy LCD module
390-643 Flat cable
391-117 Spring
391-168 Display keyboard
391-224 Knife, offset 0.45
391-288 Nameplate T1300 Pro
391-312 Roller assy
391-318 Media sensor rear assy
391-319 Media sensor front assy
391-326 Assy, pinch roller
391-342 Assy, switch pinch roller
391-344 Assy, motor
391-346 Power entry module
391-366 Endcover right
391-367 Endcover left
391-510 Core holder
391-600 Assy, tangential head
391-601 Cover head
391-655 DC motor tang. head
391-803 Fan assy
391-804 Drive drum, Assy
391-809 Motor without encoder
391-813 Belt assy D1300
391-860 Assy driver PCB 1300
391-886 Cutting strip with tape
391-935 Final control board T1300
MB0380 Belt 150T80
MB9124 Belt 110T80
MB9125 Belt 63T 2mm
ND5000-9769 Y belt spring
Accessories and Consumables
390-549 Standard Tangential Knife
Blade (Single)
390-550 Tangential knife for Masking
stencil (sandblast)
390-551 Double Tip Knife (single)
391-146 Manual Cut-Off razor Blades
(set of 10)
391-348 Razor Blade & Holder
391-360 Drag Knife Blade (set of 5)
391-500 Flange for Roll Media (single)
391-510 Flanges for Roll Media (pair)
391-596 Pouncing Tool
391-663 Tangential Knife Holder
391-664 Standard Nose Piece
391-666 Nose Piece for Masking Stencil
(sandblast)
391-667 Ballpoint Holder
391-668 Holder for Drag Knife
391-669 Ballpoint Pen
391-850 Cutter Stand (standard)
391-885 OPOS Field Upgrade Kit
423-155 Serial Interface Kit
MD9020 User’s Manual
Spare Parts List 7-
21
