SummaSign D1010 SPARE PARTS
End of Manufacture: April, 1996
Part no. Description
384-682 LCD cable
384-751 Assy LCD module
390-643 Flat cable
391-117 Spring
391-150 Display keyboard
391-200 Assy, drag head
391-222 Cover head
391-224 Knife, offset 0.45
391-227 Lock nut knife holder
391-311 Centron drag & tang
board
391-312 Roller assy
391-318 Media sensor rear assy
391-319 Media sensor front assy
391-326 Assy, pinch roller
391-332 Knife holder assy
391-342 Assy, switch pinch roller
391-344 Assy, motor
391-346 Power entry module
391-366 Endcover right
391-367 Endcover left
391-414 Drive drum, Assy
391-421 Belt assy
391-510 Set of Core holders
391-803 Fan assy
391-809 Assy motor without
encoder
391-886 Cutting strip with tape
391-935 Assy, final control board
398-198 Pulley 24 tooth +
setscrew
MB0380 Belt 150T80
MB9124 Belt 110T80
MW9987 Rom U24 rev 010
MW9988 Rom U17 rev 010
ND5000-9622 Knob coreholder
ND5000-9646 O-ring
Accessories and consumables
391-146 Manual Cut-Off Razor
Blades (set of 10)
391-332 Standard Knife Holder
391-348 Razor Blade & Holder
391-358 Sandblast Knife blade
391-360 Standard Knife Blade
391-363 Sandblast Knife Holder
391-500 Flange for Roll Media
(single)
391-510 Flanges for Roll Media (pair)
391-595 Pouncing Tool
391-785 OPOS Field upgrade kit
Drag
391-850 Cutter Stand
423-155 Serial Interface Kit
MC1184 Power Supply Cables
European type
MC3545 Power Supply Cables
American type
MI9990 User’s Manual
7-10 Spare Parts List
