Sungrow SC1200UD-US User Manual

95
11.2 Temperature Derating
11.2.1 Discharge Temperature Derating
figure 11-2 Discharge temperature derating curve of SC1200UD-US/SC1375UD-US/SC1575UD-US/
SC1725UD-US/SC2000UD-US
Ambient temp. T PCS operation situation
T<-35℃ The PCS starts with the aid of auxiliary heater
-35℃<T≤45℃ Operate for a long time at 100% of the overload condition
45℃<T≤50℃ Operate with derating at 1.82%
50℃<T≤60℃ Operate with derating at 9.09%
T>60℃ Enter protection mode;
figure 11-3 Discharge temperature derating curve of SC2500UD
Ambient temp. T PCS operation situation
T<-35℃ The PCS starts with the aid of auxiliary heater
-35℃<T≤40℃ Operate for a long time at 100% of the overload condition
40℃<T≤50℃ Operate with derating at 1%
50℃<T≤60℃ Operate with derating at 9%
T>60℃ Enter protection mode;
User Manual 11 PCS Functions
