47
6.4.4 During Connection
• Make sure the polarities of the DC cables and the phase sequence of the AC ca-
bles are correct before connection.
• Do not pull the cables hard during electrical connection.
• Make sure there is enough wire bending space for all connection cables.
• Take proper methods to reduce the stress of cables.
• Check carefully to ensure the correctness and fastness of the connections.
6.5 Cable Requirements
Choose cables according to the requirements below:
• All cables must have sufficient ampacity. The conductor ampacity is related to environ-
mental conditions, conductor insulation materials, laying, wire material and cross-sec-
tional area, etc.
• All the cables must be chosen according to the maximum current of the PCS.
• Cables for one side should be of the same type and specification.
• Flame retardant and fire resistant cables are recommended.
Recommended cable specifications are listed below.
User Manual 6 Electrical Connection
To Next Page
