45
figure 6-4 Copper-aluminum composite terminal of double-hole cable connection
Select a cable connection method based on actual needs.
When the busbar has several connection terminals, an intact copper-aluminum composite
sheet is required as shown in the following figure.
figure 6-5 Copper-aluminum composite sheet connection sequence
*The figure above is indicative only.
1 2 3
PCS copper bar Copper-aluminum compo-
site sheet
Terminal
6.4 Preparation Before Electrical Connections
6.4.1 Opening PCS Door
Open the doors before wiring.
User Manual 6 Electrical Connection
