figure 3-4 Multi-branch version(SC1200UD-US/SC1375UD-US/SC1575UD-US/SC1725UD-US)
figure 3-5 Multi-branch version(SC2000UD-US/SC2500UD-US)
*The above figures are for reference only, please refer to the actual product received.
UD series PCS support a single PV input and multiple PV inputs. Please refer to
the actual needs.
Item Name Mark
A
Communication terminal
Transfer terminals of internal communication
cables.
B
Node terminal block
Terminals of internal node information
cables.
3 Product Description User Manual
