18
The depth of the holes should be about 70 mm.
Step 2 Place the expansion tubes into the holes. Then secure the wall-mounting bracket to the
wall firmly with the expansion bolt sets.
Step 3 Lift the inverter and slide it down along the wall-mounting bracket to make sure they
match perfectly. Use the fastener set to lock the device.
-- -- EEnndd
4 Mechanical Mounting User Manual
