Sungrow SG5.0RT - Assembling the COM Connector

44
FFiigguurree 55--77 Multi-inverter Connection
• The maximum number of inverters allowed to be connected in the daisy
chain is 5.
• The RS485 communication cable should be shielded twisted pair cables or
shielded twisted pair Ethernet cables.
• The RS485 cable between two devices should be not longer than 10 m.
• The RS485 communication cannot be used simultaneously with COM1
port for WiNet-S.
5.9.2 Assembling the COM Connector
Step 1 Unscrew the swivel nut from the connector.
Step 2 Take out the terminal block.
Step 3 Remove the seal and lead the cable through the cable gland.
5 Electrical Connection User Manual
