3 Function Description User Manual
14
When Vmin < V < 230 V, P = Pn ×(V
grid
/ 230 V)
Refer to “12.3.1 Volt-watt Response” for over-voltage c ur ve. The following figure
shows the under-voltage derating curve.
V
min
P
n
230V
Normally
working area
Fig. 3-1 Grid Under-voltage Derating
Export Power Limit Derating
When the meter detects that the export power is greater than the limit value on the
LCD, the inverter will reduce the output power within the specified range.
Power Factor Derating
When the power factor PF<1.0, the inverter will reduce the output power within a
specified range. The following figure shows the power factor derating curve.
Fig. 3-2 Power Factor Derating
