User Manual 10 Appendix I: LCD Operation
79
Refer to the following table for the fault type explanations.
Fault Type Explanation
GRID Grid faults (AC side)
PV PV faults (DC side)
SYS System faults (inverter)
PER Permanent faults
WARN Warnings
BDCF Faults of battery charge/discharge circuit
BDCPF Permanent faults of battery charge/discharge circuit
BATW Battery warnings
BATP Battery protection
BATF1
Battery faults
BATF2
Viewing Fault Records
Main Screen (Press ENT)→Menu (Press ×5)→Fault Record (Press ENT)
Press
/ to turn pages and view all fault
records.
10.6 Starting and Stopping the Inverter
Main Screen (Press ENT)→Menu (Press ×1)→ON / OFF (Press ENT)
Notice:
The Restart item will appear only if an unrecoverable
fault occurs.
Confirm your choice by pressing ENT.
