LOCATING AND USING PARTS OF THE CONTROLLER BOX
1) Left and right side of control box
2) Rear panel
① Caution
② Motor
③ AC INPUT
②
③
33
Motor Power Cable
AC Power switch
Standard Solenoid
Connector
Switch and Lamp
Foot-lift Solenoid(Green)
Right lift Solenoid(Blue)
Tension-release and
Auxiliary solenoid(White)
Hazardous voltage will cause injury.
Be sure to wait at least 360 seconds before
opening this cover after turn off main switch and
unplug power cord.
고압 전류에 의해 감전될 수 있으므로 커버를 열 때
는 전원을 내리고 전원 플러그를 뽑고 나서 360초간
기다린 후 여십시오.
WARNING
경고
Encoder Connector
(Green)
OPTION
Connector for Position
Sensor(Black)
Program Unit
Connector(White)
①
