SunStar KM-235 - For 24 V-Regular Solenoid; For 30 V-Regular Solenoid; Setting of Pin

22
② Set Value for electric voltage suplied (for 110V series) for Solenoid against the incoming voltage.
③ Setting of pin
For 30V-regular Solenoid For 24V-regular Solenoid
Incoming Voltage Set Value
Below 100V J5
100V~120V J6
Above 120V J7
Incoming Voltage Set Value
Below 90V J5
90V~100V J6
Above 100V J7
