1. Safety instruction 6
2. Precautions before use
8
3. Locating and using parts of the controller box
10
4. Installation
11
1) Mounting your Servo Motor on the table 11
2) Assembling the belt cover and adjusting the belt tension 12
3) Mounting and adjusting the foot-lift solenoid 13
4) Mounting the position sensor (Synchronizer) and setting the film 14
5) How to equip and adjust a built-in location detector(synchronizer) 16
6) Mounting the Program Unit(P/U) 18
7) An example of installing the SunStar sewing machine 19
5. Wiring and grounding 20
1) Specification of the power plug 20
2) Specification of electric current in wiring of power plug 20
3) Name and description on the outside connector of control box 21
4) How to change the electric voltage supplied for solenoid(The factory installed setting is:J2)
21
6. Connection the earth wire of the sewing machine and motor 23
7. Things to be checked after installation
23
8. Program unit part names and method of use
24
1) Program unit part names 24
2) Program Unit Method of Use 24
3) Start and End Backtack Stitch Correction Method 35
4) Method of Use: Inertia Tuning Function 38
5) How to Use Edge Sensor 39
6) Motor Controller Setting 42
7) Advanced Pattern Sewing Functions 46
8) Automatic Change Function of Twin Needles (applicable to the models supporting twin needles)
48
9. Simple operation unit part names and method of use 50
1) Names of Each Part in the Simple Operation Unit 50
2) Simple Program Unit Method of Use 50
10. Fortuna series 5 full function software method of use 55
1) Basic Functions of the Fortuna Series 5 Full Function Software 55
2) Fortuna Series 5 Full Function Software Specific Parameters 56
3) Method of Use and Explanations for Specific Items of the Parameter
71
4) Thread Trimming Sequence Function Method of Use (Items no. 54, 55, 56 of Group B)
75
11. Breakdown and troubleshooting 84
12. How to place for controller
85
13. Block diagram
86
※Parts Book
87
CCOONNTTEENNTTSS
