SunStar KM-235 - Built-in Location Detector (Synchronizer)

16
5) How to equip and adjust a built-in location
detector(synchronizer)
(1) How to equip the built-in location detector
(synchronizer)
▶ In case of a SunStar thread trimmer
When a built-in location detector(synchronizer) for the
sewing machine with the SunStar thread trimmer is
equipped, all that the users need to do is to simply adjust the
location of magnetic for detection according to their needs.
Locate detector
(synchronizer)
Position magnetic up
Upper
Shaft
Position magnetic down
Position magnetic up
Sewing machine
pulley
Locate detector
(synchronizer)
Position
magnetic down
Sewing machine
